4-inch Electric Contact Pressure Gauge with 0-0.6MPa Range and Switch Gauge Combo

Deskripsi Produk

Electric Contact Pressure Gauge 4" 100mm | 0-0.6MPa | Switch & Gauge Combo

Dual-Purpose Control Gauge

Our 4-inch (100mm) Electric Contact Pressure Gauge is a versatile hybrid instrument that combines precise pressure indication with reliable electrical switching capability. With a clear 0-0.6MPa scale, this electrical contact pressure gauge serves both as a visual manometer and an automatic control device, making it an indispensable component for pump control, alarm systems, and process automation where pressure limits must be monitored and acted upon automatically.

Key Features & Benefits

All-in-One Functionality: This electric contact manometer integrates a precise pressure gauge with one or two adjustable set-point switches, eliminating the need for separate gauges and switches, saving space and cost.
Reliable Switching: Built-in micro-switches provide stable electrical contact for controlling pumps, compressors, alarms, or solenoid valves directly based on system pressure.
Clear Visual Monitoring: The large 4-inch dial ensures excellent readability of the 0-0.6MPa pressure, allowing for both automatic control and manual verification.
Adjustable Set Points: The high and/or low alarm or control set points can be easily adjusted externally (via a dial key) or internally to match your system's requirements.
Durable Construction: Designed for continuous industrial use with a robust case and reliable switching mechanism rated for frequent cycles.

Technical Specifications

Specification	Detail
Dial Size	4 inches / 100 mm
Pressure Range	0-0.6MPa
Function	Electric Contact Pressure Gauge (Gauge + Switch)
Contact Configuration	SPDT (Single-Pole, Double-Throw) - Typically 1 or 2 switches
Switch Rating	15A @ 250VAC (or similar, depending on model)
Adjustability	Externally or Internally Adjustable Set Points
Connection Type	Radial (Bottom/Back Process Connection)
Electrical Connection	Screw Terminal Block
Accuracy (Gauge)	1.6% FS

How an Electric Contact Manometer Works

An electric contact pressure gauge operates on a simple, reliable principle:

Pressure Measurement: System pressure moves the Bourdon tube and pointer as in a standard gauge.
Electrical Activation: The pointer shaft is linked to one or more miniature switches. When the pointer reaches a pre-set pressure value (e.g., 0.4MPa for "Pump Off"), it physically activates the switch.
Circuit Control: The switch opens or closes an electrical circuit connected to it (e.g., cutting power to a pump motor, activating a warning light, or sounding an alarm).
Visual Confirmation: The operator can always see the current pressure on the dial and the position of the set-point pointers.

Typical Applications

This electrical contact pressure gauge is ideal for automatic control in:

Water Pump Control: Automatically start/stop well pumps or booster pumps based on tank pressure.
Compressor Control: Maintain air receiver pressure between set limits.
Safety Alarms: Activate visual or audible alarms for over-pressure or under-pressure conditions in boilers, hydraulic systems, or process vessels.
Industrial Automation: Provide simple, reliable switching for automated production lines.
HVAC Systems: Control pumps or signal alarms in heating and cooling circuits.

Ordering & Technical Support

Selecting the correct switch rating, contact configuration (SPDT, DPDT), and adjustment type is crucial for your application. For assistance with sizing, wiring diagrams, or custom configurations, please contact our technical support team.
